group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
0 | 26 | 0 | 12 | 7.98 | 73.64 | -16.63 | 83.91 | 0.2880 |
previous
or next day for the same group /
back to the solar disc Gyula 1981-10-05 12:04:32 UT ![]() |
spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
0 | 1 | 0 | 1 | 6.66 | 80.39 | -9.86 | 88.35 | 0.1710 | |
0 | 0 | 0 | 0 | 4.24 | 78.02 | -12.24 | 99.77 | 0.2155 | |
0 | 2 | 0 | 1 | 5.18 | 78.07 | -12.20 | 95.44 | 0.2124 | |
0 | 1 | 0 | 0 | 4.33 | 76.07 | -14.20 | 97.92 | 0.2480 | |
0 | 1 | 0 | 0 | 8.80 | 76.23 | -14.04 | 79.63 | 0.2448 | |
0 | 3 | 0 | 2 | 8.54 | 75.82 | -14.44 | 80.89 | 0.2508 | |
0 | 1 | 0 | 1 | 9.91 | 74.23 | -16.04 | 76.74 | 0.2810 | |
0 | 0 | 0 | 0 | 8.28 | 72.90 | -17.37 | 82.95 | 0.2991 | |
0 | 1 | 0 | 0 | 6.17 | 71.77 | -18.50 | 89.92 | 0.3169 | |
0 | 3 | 0 | 1 | 7.80 | 72.24 | -18.03 | 84.67 | 0.3093 | |
0 | 5 | 0 | 3 | 10.65 | 72.93 | -17.33 | 75.10 | 0.3043 | |
0 | 1 | 0 | 0 | 11.20 | 72.60 | -17.68 | 73.61 | 0.3119 | |
0 | 5 | 0 | 2 | 5.85 | 69.37 | -20.89 | 90.57 | 0.3564 | |
0 | 1 | 0 | 1 | 7.24 | 69.72 | -20.56 | 86.63 | 0.3505 | |
0 | 1 | 0 | 0 | 6.64 | 69.19 | -21.08 | 88.33 | 0.3590 |
Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
B | - Heliographic latitude B; positive: North, negative: South | |
L | - Heliographic longitude L | |
LCM | - Longitudinal distance from the Sun's central meridian | |
Pos. angle | - Position angle | |
r | - Distance from the centre of Sun's disc in terms of Sun's radius |
