Kanzelhoehe 2000-01-07 09:24:18 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 6 | 38 | 2 | 20 | 15.75 | 272.79 | -11.06 | 28.99 | 0.3817 | |
|
next day for the same group /
back to the solar disc Kanzelhoehe 2000-01-07 09:24:18 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 2 | 13 | 1 | 7 | 15.44 | 274.33 | -9.51 | 25.99 | 0.3652 | |
| 1 | 8 | 0 | 4 | 14.86 | 273.46 | -10.39 | 28.79 | 0.3634 | |
| 3 | 11 | 1 | 6 | 16.73 | 271.74 | -12.11 | 30.04 | 0.4032 | |
| 0 | 2 | 0 | 1 | 16.20 | 271.82 | -12.04 | 30.60 | 0.3953 | |
| 0 | 2 | 0 | 1 | 15.35 | 271.87 | -12.00 | 31.68 | 0.3834 | |
| 0 | 1 | 0 | 0 | 15.48 | 269.34 | -14.52 | 36.52 | 0.4078 | |
| 0 | 1 | 0 | 1 | 15.66 | 268.82 | -15.05 | 37.21 | 0.4151 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
