SOHO MDI 2000-01-12 15:59:32 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 58 | 410 | 34 | 238 | 26.64 | 208.42 | -6.17 | 10.31 | 0.5253 | |
|
previous
or next day for the same group /
back to the solar disc SOHO MDI 2000-01-12 15:59:32 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 14 | 327 | 8 | 188 | 25.78 | 210.09 | -4.50 | 8.04 | 0.5074 | |
| 36 | -1 | 21 | -1 | 26.14 | 209.82 | -4.77 | 8.40 | 0.5133 | |
| 0 | 4 | 0 | 2 | 23.56 | 209.62 | -4.97 | 9.66 | 0.4750 | |
| 8 | 23 | 5 | 14 | 28.56 | 205.89 | -8.70 | 13.79 | 0.5595 | |
| 0 | 3 | 0 | 2 | 29.22 | 204.64 | -9.95 | 15.32 | 0.5731 | |
| 0 | 5 | 0 | 3 | 29.18 | 204.33 | -10.26 | 15.79 | 0.5737 | |
| 0 | 6 | 0 | 4 | 29.08 | 201.75 | -12.84 | 19.52 | 0.5836 | |
| 0 | 5 | 0 | 3 | 30.52 | 201.19 | -13.40 | 19.34 | 0.6050 | |
| 0 | 7 | 0 | 4 | 29.78 | 201.25 | -13.34 | 19.74 | 0.5951 | |
| 0 | 8 | 0 | 5 | 29.28 | 200.91 | -13.68 | 20.54 | 0.5903 | |
| 0 | 14 | 0 | 8 | 29.01 | 200.58 | -14.00 | 21.16 | 0.5884 | |
| 0 | 8 | 0 | 5 | 29.27 | 199.05 | -15.54 | 23.02 | 0.5998 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
