Gyula 2000-01-15 12:09:24 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 44 | 378 | 32 | 274 | -17.48 | 131.07 | -45.92 | 109.81 | 0.7299 | |
|
previous
or next day for the same group /
back to the solar disc Gyula 2000-01-15 12:09:24 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 0 | 1 | 0 | 0 | -18.89 | 135.63 | -41.35 | 113.08 | 0.6819 | |
| 20 | 193 | 14 | 134 | -16.48 | 133.56 | -43.44 | 109.05 | 0.6999 | |
| 3 | -2 | 2 | -2 | -16.76 | 133.23 | -43.77 | 109.36 | 0.7044 | |
| 2 | -2 | 1 | -2 | -17.46 | 132.51 | -44.46 | 110.15 | 0.7140 | |
| 1 | -2 | 0 | -2 | -16.65 | 132.56 | -44.41 | 109.04 | 0.7116 | |
| 0 | 1 | 0 | 1 | -14.97 | 131.43 | -45.56 | 106.47 | 0.7216 | |
| 1 | 63 | 1 | 46 | -17.40 | 130.67 | -46.30 | 109.61 | 0.7348 | |
| 0 | 1 | 0 | 1 | -15.99 | 130.90 | -46.07 | 107.76 | 0.7293 | |
| 9 | -7 | 7 | -7 | -17.12 | 130.60 | -46.37 | 109.22 | 0.7350 | |
| 0 | 2 | 0 | 1 | -18.86 | 129.93 | -47.04 | 111.38 | 0.7461 | |
| -9 | -7 | -9 | -7 | -17.05 | 130.27 | -46.72 | 109.05 | 0.7387 | |
| 0 | 1 | 0 | 1 | -19.20 | 129.13 | -47.84 | 111.63 | 0.7555 | |
| 0 | 1 | 0 | 1 | -21.05 | 127.85 | -49.14 | 113.69 | 0.7731 | |
| 1 | 114 | 1 | 88 | -19.15 | 128.26 | -48.71 | 111.36 | 0.7645 | |
| 5 | -14 | 4 | -14 | -18.81 | 128.00 | -49.00 | 110.85 | 0.7668 | |
| 1 | -14 | 1 | -14 | -19.27 | 127.77 | -49.21 | 111.41 | 0.7699 | |
| 1 | -14 | 1 | -14 | -19.36 | 127.37 | -49.61 | 111.43 | 0.7743 | |
| 0 | -14 | 0 | -14 | -19.23 | 127.06 | -49.91 | 111.20 | 0.7771 | |
| 0 | 1 | 0 | 1 | -18.68 | 125.92 | -51.05 | 110.27 | 0.7877 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
