Kanzelhoehe 2000-01-27 08:42:37 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 98 | 631 | 78 | 504 | 5.08 | 71.52 | 50.63 | 281.13 | 0.7858 | |
|
previous
or next day for the same group /
back to the solar disc Kanzelhoehe 2000-01-27 08:42:37 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 20 | 168 | 18 | 150 | 3.89 | 76.61 | 55.73 | 278.46 | 0.8357 | |
| 6 | -1 | 5 | -1 | 4.35 | 76.12 | 55.22 | 279.11 | 0.8316 | |
| 0 | 2 | 0 | 2 | 2.85 | 75.79 | 54.88 | 277.38 | 0.8260 | |
| 0 | 8 | 0 | 7 | 4.23 | 75.16 | 54.25 | 279.16 | 0.8221 | |
| 1 | 11 | 0 | 10 | 4.45 | 74.47 | 53.59 | 279.57 | 0.8159 | |
| 3 | 14 | 3 | 11 | 3.64 | 74.11 | 53.23 | 278.66 | 0.8109 | |
| 0 | 1 | 0 | 1 | 4.00 | 73.68 | 52.80 | 279.19 | 0.8072 | |
| 0 | 3 | 0 | 2 | 4.81 | 72.70 | 51.80 | 280.41 | 0.7985 | |
| 2 | 15 | 2 | 12 | 5.40 | 72.14 | 51.26 | 281.26 | 0.7941 | |
| 0 | 1 | 0 | 0 | 3.27 | 72.43 | 51.53 | 278.56 | 0.7927 | |
| 0 | 1 | 0 | 1 | 3.36 | 72.03 | 51.12 | 278.76 | 0.7886 | |
| 0 | 3 | 0 | 2 | 3.27 | 71.31 | 50.40 | 278.81 | 0.7808 | |
| 3 | 404 | 2 | 306 | 3.99 | 70.07 | 49.16 | 280.01 | 0.7687 | |
| 8 | -13 | 6 | -13 | 4.66 | 69.49 | 48.61 | 281.00 | 0.7641 | |
| 1 | -13 | 1 | -13 | 6.10 | 68.75 | 47.86 | 283.07 | 0.7592 | |
| 16 | -13 | 12 | -13 | 5.15 | 68.88 | 48.00 | 281.81 | 0.7585 | |
| 9 | -13 | 7 | -13 | 4.65 | 68.90 | 47.99 | 281.16 | 0.7572 | |
| 29 | -13 | 22 | -13 | 6.84 | 68.27 | 47.39 | 284.17 | 0.7560 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
