| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 117 | 614 | 66 | 347 | 21.45 | 18.93 | -3.73 | 7.25 | 0.4837 | |
|
previous
or next day for the same group /
back to the solar disc Gyula 2000-02-23 13:38:17 UT ![]() |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 106 | 541 | 60 | 306 | 21.63 | 19.22 | -3.44 | 6.63 | 0.4857 | |
| 0 | 6 | 0 | 3 | 20.07 | 17.82 | -4.84 | 9.86 | 0.4651 | |
| 0 | 1 | 0 | 0 | 21.41 | 16.97 | -5.70 | 10.98 | 0.4876 | |
| 7 | 20 | 4 | 11 | 20.30 | 17.36 | -5.30 | 10.67 | 0.4698 | |
| 1 | 5 | 0 | 3 | 19.80 | 17.44 | -5.21 | 10.71 | 0.4620 | |
| 0 | 5 | 0 | 3 | 20.99 | 16.86 | -5.80 | 11.35 | 0.4817 | |
| 1 | 32 | 1 | 18 | 19.20 | 17.13 | -5.54 | 11.64 | 0.4538 | |
| 1 | -7 | 1 | -7 | 19.13 | 16.95 | -5.71 | 12.01 | 0.4533 | |
| 1 | -7 | 0 | -7 | 19.51 | 16.78 | -5.88 | 12.17 | 0.4596 | |
| 0 | 3 | 0 | 2 | 25.50 | 12.16 | -10.50 | 17.04 | 0.5638 | |
| 0 | 1 | 0 | 1 | 21.98 | 9.40 | -13.27 | 23.79 | 0.5300 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
