Gyula 2000-02-24 12:57:44 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 52 | 494 | 37 | 339 | 12.51 | 330.97 | -38.89 | 63.14 | 0.6883 | |
|
previous
or next day for the same group /
back to the solar disc Gyula 2000-02-24 12:57:44 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 29 | 314 | 19 | 208 | 12.40 | 333.47 | -36.39 | 61.80 | 0.6597 | |
| 0 | 3 | 0 | 2 | 10.57 | 334.37 | -35.46 | 63.74 | 0.6382 | |
| 0 | -1 | 0 | -1 | 12.33 | 332.20 | -37.66 | 62.72 | 0.6739 | |
| 1 | -1 | 1 | -1 | 12.13 | 332.25 | -37.61 | 62.96 | 0.6722 | |
| 8 | -1 | 5 | -1 | 12.45 | 331.88 | -37.98 | 62.76 | 0.6782 | |
| 1 | -1 | 1 | -1 | 12.79 | 331.28 | -38.57 | 62.67 | 0.6868 | |
| 0 | 4 | 0 | 3 | 12.06 | 331.11 | -38.75 | 63.74 | 0.6848 | |
| 0 | 3 | 0 | 2 | 12.73 | 330.71 | -39.12 | 63.07 | 0.6926 | |
| 0 | 1 | 0 | 1 | 13.13 | 330.39 | -39.44 | 62.74 | 0.6983 | |
| 0 | 1 | 0 | 1 | 13.34 | 330.01 | -39.82 | 62.70 | 0.7036 | |
| 0 | 4 | 0 | 3 | 11.63 | 330.91 | -38.93 | 64.43 | 0.6847 | |
| 0 | 1 | 0 | 1 | 13.42 | 328.93 | -40.92 | 63.22 | 0.7160 | |
| 1 | 131 | 1 | 95 | 13.41 | 328.25 | -41.60 | 63.62 | 0.7233 | |
| 0 | 1 | 0 | 1 | 11.42 | 329.12 | -40.74 | 65.71 | 0.7041 | |
| 0 | 1 | 0 | 1 | 12.08 | 328.20 | -41.64 | 65.34 | 0.7173 | |
| 1 | -13 | 1 | -13 | 13.01 | 327.38 | -42.47 | 64.59 | 0.7308 | |
| 3 | 12 | 2 | 8 | 11.35 | 328.30 | -41.55 | 66.24 | 0.7129 | |
| 0 | 0 | 0 | 0 | 11.60 | 328.04 | -41.81 | 66.04 | 0.7170 | |
| 5 | -13 | 4 | -13 | 12.89 | 327.07 | -42.79 | 64.91 | 0.7335 | |
| 0 | 2 | 0 | 1 | 10.76 | 328.27 | -41.59 | 67.03 | 0.7106 | |
| 1 | -13 | 1 | -13 | 13.14 | 326.80 | -43.06 | 64.73 | 0.7375 | |
| 0 | -13 | 0 | -13 | 12.72 | 326.74 | -43.08 | 65.27 | 0.7359 | |
| 0 | 1 | 0 | 1 | 11.31 | 327.29 | -42.56 | 66.80 | 0.7239 | |
| 2 | 15 | 2 | 11 | 11.80 | 327.01 | -42.84 | 66.32 | 0.7292 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
