Gyula 2000-03-05 10:31:22 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 9 | 73 | 5 | 44 | 19.38 | 234.96 | -4.52 | 9.22 | 0.4571 | |
|
previous
or next day for the same group /
back to the solar disc Gyula 2000-03-05 10:31:22 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 0 | 1 | 0 | 1 | 20.61 | 237.56 | -1.91 | 3.82 | 0.4703 | |
| 0 | 0 | 0 | 0 | 20.87 | 237.30 | -2.18 | 4.31 | 0.4745 | |
| 0 | 1 | 0 | 1 | 18.28 | 237.19 | -2.28 | 5.01 | 0.4343 | |
| 9 | 43 | 5 | 24 | 18.78 | 236.71 | -2.77 | 5.95 | 0.4429 | |
| 0 | 5 | 0 | 3 | 19.30 | 235.42 | -4.05 | 8.48 | 0.4535 | |
| 0 | 3 | 0 | 2 | 19.75 | 234.70 | -4.77 | 9.79 | 0.4623 | |
| 0 | 4 | 0 | 2 | 19.63 | 232.46 | -7.01 | 14.30 | 0.4675 | |
| 0 | 0 | 0 | 0 | 20.88 | 231.87 | -7.60 | 14.72 | 0.4884 | |
| 0 | 4 | 0 | 2 | 20.41 | 231.82 | -7.65 | 15.08 | 0.4816 | |
| 0 | 1 | 0 | 1 | 20.03 | 231.98 | -7.49 | 15.00 | 0.4755 | |
| 0 | 2 | 0 | 1 | 20.66 | 231.57 | -7.91 | 15.41 | 0.4864 | |
| 0 | 1 | 0 | 1 | 20.79 | 231.41 | -8.06 | 15.62 | 0.4889 | |
| 0 | 1 | 0 | 1 | 20.72 | 230.71 | -8.77 | 16.95 | 0.4909 | |
| 0 | 1 | 0 | 1 | 20.98 | 230.34 | -9.13 | 17.44 | 0.4963 | |
| 0 | 3 | 0 | 2 | 20.14 | 230.86 | -8.62 | 17.05 | 0.4817 | |
| 0 | 1 | 0 | 1 | 21.02 | 230.13 | -9.34 | 17.80 | 0.4978 | |
| 0 | 2 | 0 | 1 | 20.39 | 230.31 | -9.16 | 17.89 | 0.4878 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
