| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 8 | 42 | 4 | 21 | -17.14 | 143.77 | -5.16 | 153.88 | 0.1953 | |
|
previous
or next day for the same group /
back to the solar disc Gyula 2000-03-12 07:25:22 UT ![]() |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 0 | 3 | 0 | 1 | -16.70 | 149.77 | 0.84 | 184.88 | 0.1664 | |
| 0 | 5 | 0 | 2 | -16.36 | 143.93 | -5.01 | 152.30 | 0.1810 | |
| 0 | 1 | 0 | 1 | -15.87 | 143.54 | -5.38 | 149.19 | 0.1768 | |
| 0 | 1 | 0 | 1 | -15.96 | 143.34 | -5.58 | 148.56 | 0.1800 | |
| 8 | 28 | 4 | 14 | -17.27 | 143.74 | -5.19 | 153.77 | 0.1963 | |
| -5 | -5 | -5 | -5 | -17.37 | 143.52 | -5.43 | 152.98 | 0.1996 | |
| 0 | 2 | 0 | 1 | -16.39 | 143.02 | -5.90 | 148.39 | 0.1890 | |
| 0 | 1 | 0 | 0 | -17.70 | 141.79 | -7.13 | 147.13 | 0.2189 | |
| 0 | 1 | 0 | 1 | -19.59 | 141.71 | -7.21 | 151.25 | 0.2469 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
