Gyula 2000-03-13 06:33:45 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 8 | 26 | 5 | 15 | -13.26 | 163.04 | 26.80 | 254.54 | 0.4569 | |
|
previous
or next day for the same group /
back to the solar disc Gyula 2000-03-13 06:33:45 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 5 | 16 | 3 | 9 | -12.66 | 165.27 | 29.03 | 256.86 | 0.4883 | |
| 0 | 2 | 0 | 1 | -12.21 | 163.39 | 27.15 | 257.25 | 0.4592 | |
| 3 | 5 | 2 | 3 | -14.87 | 159.72 | 23.49 | 249.56 | 0.4129 | |
| 0 | 3 | 0 | 2 | -14.08 | 157.81 | 21.57 | 250.19 | 0.3807 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
