Gyula 2000-04-23 06:32:30 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 6 | 36 | 8 | 56 | -20.95 | 26.72 | 71.46 | 249.45 | 0.9442 | |
|
previous
day for the same group /
back to the solar disc Gyula 2000-04-23 06:32:30 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 0 | 4 | 0 | 9 | -21.09 | 35.09 | 79.85 | 249.44 | 0.9818 | |
| 0 | 0 | 0 | 1 | -21.13 | 32.25 | 77.00 | 249.42 | 0.9719 | |
| 0 | 2 | 0 | 4 | -22.08 | 32.92 | 77.67 | 248.44 | 0.9744 | |
| 6 | 29 | 8 | 40 | -20.75 | 24.23 | 68.96 | 249.61 | 0.9327 | |
| 0 | 1 | 0 | 2 | -21.84 | 23.81 | 68.56 | 248.41 | 0.9308 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
