| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 5 | 73 | 6 | 74 | 19.53 | 235.82 | 57.76 | 294.77 | 0.8796 | |
|
previous
or next day for the same group /
back to the solar disc Gyula 2000-05-03 15:43:32 UT ![]() |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 1 | 53 | 1 | 56 | 19.09 | 236.93 | 58.87 | 293.94 | 0.8870 | |
| 1 | -1 | 1 | -1 | 19.69 | 236.65 | 58.59 | 294.68 | 0.8863 | |
| 1 | -1 | 1 | -1 | 19.45 | 236.64 | 58.58 | 294.43 | 0.8856 | |
| 1 | -1 | 2 | -1 | 19.22 | 236.43 | 58.38 | 294.23 | 0.8837 | |
| 0 | 1 | 0 | 1 | 18.65 | 236.10 | 58.03 | 293.70 | 0.8798 | |
| 1 | 6 | 1 | 6 | 19.95 | 235.62 | 57.55 | 295.27 | 0.8791 | |
| 0 | 1 | 0 | 1 | 19.00 | 234.28 | 56.22 | 294.63 | 0.8666 | |
| 0 | 0 | 0 | 0 | 20.17 | 233.61 | 55.56 | 296.13 | 0.8643 | |
| 0 | 2 | 0 | 2 | 19.06 | 233.24 | 55.19 | 295.02 | 0.8584 | |
| 0 | 2 | 0 | 2 | 19.77 | 232.72 | 54.66 | 295.98 | 0.8560 | |
| 0 | 0 | 0 | 0 | 19.27 | 232.67 | 54.62 | 295.44 | 0.8543 | |
| 0 | 1 | 0 | 1 | 19.06 | 232.66 | 54.61 | 295.21 | 0.8537 | |
| 0 | 3 | 0 | 2 | 20.45 | 232.09 | 54.04 | 296.95 | 0.8529 | |
| 0 | 2 | 0 | 1 | 22.22 | 229.77 | 51.72 | 299.78 | 0.8394 | |
| 0 | 2 | 0 | 2 | 22.51 | 229.33 | 51.28 | 300.29 | 0.8368 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
