Gyula 2000-05-27 10:18:42 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 32 | 181 | 24 | 147 | -35.48 | 265.65 | 42.02 | 223.78 | 0.7899 | |
|
previous
or next day for the same group /
back to the solar disc Gyula 2000-05-27 10:18:42 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 3 | 53 | 2 | 44 | -34.35 | 268.82 | 45.19 | 226.68 | 0.8072 | |
| 2 | -1 | 1 | -1 | -34.17 | 268.34 | 44.71 | 226.65 | 0.8027 | |
| 1 | -1 | 1 | -1 | -34.64 | 268.47 | 44.84 | 226.20 | 0.8060 | |
| 5 | 46 | 4 | 38 | -34.54 | 267.30 | 43.66 | 225.72 | 0.7966 | |
| 1 | -4 | 0 | -4 | -34.70 | 266.74 | 43.11 | 225.26 | 0.7933 | |
| 3 | -4 | 3 | -4 | -34.91 | 266.61 | 42.99 | 224.97 | 0.7935 | |
| 0 | -4 | 0 | -4 | -34.94 | 265.99 | 42.38 | 224.61 | 0.7891 | |
| 0 | 1 | 0 | 1 | -34.48 | 264.08 | 40.44 | 224.03 | 0.7716 | |
| 0 | 2 | 0 | 1 | -34.73 | 264.16 | 40.53 | 223.81 | 0.7738 | |
| 3 | 11 | 2 | 9 | -36.08 | 263.76 | 40.12 | 222.11 | 0.7789 | |
| 0 | 4 | 0 | 4 | -37.01 | 264.13 | 40.50 | 221.35 | 0.7873 | |
| 2 | 64 | 1 | 50 | -36.29 | 262.92 | 39.30 | 221.40 | 0.7742 | |
| 3 | -12 | 2 | -12 | -36.38 | 262.76 | 39.12 | 221.20 | 0.7735 | |
| 3 | -12 | 3 | -12 | -36.72 | 262.48 | 38.84 | 220.67 | 0.7736 | |
| 6 | -12 | 5 | -12 | -37.19 | 262.49 | 38.85 | 220.19 | 0.7767 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
