| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 15 | 65 | 7 | 38 | 12.18 | 120.97 | 29.66 | 293.53 | 0.5294 | |
|
previous
or next day for the same group /
back to the solar disc Gyula 2000-06-06 10:15:40 UT ![]() |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 2 | 6 | 1 | 4 | 13.03 | 124.45 | 33.13 | 292.90 | 0.5803 | |
| 1 | 5 | 0 | 3 | 12.83 | 123.79 | 32.48 | 292.94 | 0.5707 | |
| 0 | 1 | 0 | 1 | 13.24 | 123.58 | 32.27 | 293.73 | 0.5699 | |
| 0 | 0 | 0 | 0 | 12.14 | 122.15 | 30.84 | 292.72 | 0.5454 | |
| 0 | 3 | 0 | 2 | 13.26 | 120.31 | 29.00 | 295.87 | 0.5265 | |
| 0 | 2 | 0 | 1 | 12.84 | 120.13 | 28.82 | 295.26 | 0.5217 | |
| 6 | 47 | 3 | 27 | 11.96 | 120.17 | 28.86 | 293.64 | 0.5175 | |
| 6 | -7 | 3 | -7 | 11.68 | 120.14 | 28.83 | 293.16 | 0.5156 | |
| 0 | -7 | 0 | -7 | 12.40 | 119.99 | 28.68 | 294.56 | 0.5174 | |
| 0 | 1 | 0 | 0 | 11.86 | 118.73 | 27.42 | 294.48 | 0.4971 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
