Gyula 2000-06-09 16:03:19 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 0 | 19 | 0 | 10 | -24.86 | 55.67 | 7.24 | 195.09 | 0.4470 | |
|
previous
or next day for the same group /
back to the solar disc Gyula 2000-06-09 16:03:19 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 0 | 3 | 0 | 2 | -22.89 | 59.28 | 10.85 | 203.67 | 0.4338 | |
| 0 | 3 | 0 | 1 | -26.77 | 58.33 | 9.90 | 198.57 | 0.4839 | |
| 0 | 4 | 0 | 2 | -24.06 | 57.08 | 8.65 | 198.33 | 0.4383 | |
| 0 | 2 | 0 | 1 | -25.08 | 56.96 | 8.53 | 197.33 | 0.4528 | |
| 0 | 5 | 0 | 3 | -24.95 | 53.98 | 5.55 | 191.56 | 0.4392 | |
| 0 | 1 | 0 | 1 | -27.06 | 49.35 | 0.92 | 181.78 | 0.4637 | |
| 0 | 1 | 0 | 0 | -27.29 | 49.21 | 0.78 | 181.49 | 0.4672 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
