| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 26 | 90 | 13 | 46 | 16.11 | 188.66 | -10.32 | 35.51 | 0.2964 | |
|
previous
or next day for the same group /
back to the solar disc Gyula 2000-06-25 11:47:40 UT ![]() |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 1 | 6 | 0 | 3 | 14.83 | 190.87 | -8.12 | 32.10 | 0.2580 | |
| 9 | 25 | 4 | 13 | 15.23 | 190.41 | -8.57 | 32.66 | 0.2677 | |
| 1 | -2 | 0 | -2 | 15.68 | 190.41 | -8.59 | 31.79 | 0.2743 | |
| 0 | -2 | 0 | -2 | 15.15 | 190.33 | -8.67 | 33.13 | 0.2675 | |
| 0 | 0 | 0 | 0 | 14.83 | 190.18 | -8.83 | 34.28 | 0.2645 | |
| 3 | 10 | 2 | 5 | 16.38 | 188.90 | -10.08 | 34.54 | 0.2976 | |
| 0 | 7 | 0 | 4 | 15.98 | 188.28 | -10.71 | 36.97 | 0.2983 | |
| 0 | 1 | 0 | 0 | 15.55 | 188.00 | -11.00 | 38.61 | 0.2958 | |
| 5 | 18 | 3 | 9 | 16.68 | 187.63 | -11.36 | 37.13 | 0.3139 | |
| 7 | 23 | 4 | 12 | 16.89 | 187.10 | -11.89 | 37.94 | 0.3221 | |
| -10 | -10 | -10 | -10 | 16.89 | 186.94 | -12.05 | 38.30 | 0.3237 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
