Gyula 2000-06-30 05:11:15 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 29 | 172 | 15 | 88 | -13.33 | 134.03 | -2.41 | 171.65 | 0.2826 | |
|
previous
or next day for the same group /
back to the solar disc Gyula 2000-06-30 05:11:15 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 29 | 170 | 15 | 88 | -13.33 | 134.10 | -2.34 | 171.86 | 0.2822 | |
| 0 | 1 | 0 | 0 | -13.50 | 126.80 | -9.65 | 149.81 | 0.3257 | |
| 0 | 1 | 0 | 0 | -13.02 | 126.20 | -10.26 | 147.48 | 0.3242 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
