| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 33 | 182 | 25 | 140 | -34.38 | 331.59 | -30.12 | 147.08 | 0.7632 | |
|
next day for the same group /
back to the solar disc Gyula 2000-08-06 14:36:52 UT ![]() |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 22 | 134 | 16 | 101 | -34.15 | 332.80 | -28.91 | 147.84 | 0.7539 | |
| 0 | 1 | 0 | 1 | -36.44 | 330.76 | -30.96 | 148.10 | 0.7854 | |
| 0 | 2 | 0 | 1 | -36.17 | 330.89 | -30.83 | 147.98 | 0.7824 | |
| 0 | 1 | 0 | 1 | -36.75 | 330.37 | -31.35 | 148.06 | 0.7901 | |
| 0 | 2 | 0 | 2 | -35.92 | 330.09 | -31.63 | 147.14 | 0.7850 | |
| 0 | 1 | 0 | 1 | -34.19 | 330.64 | -31.07 | 146.09 | 0.7675 | |
| 5 | 16 | 4 | 13 | -35.29 | 328.60 | -33.11 | 145.47 | 0.7889 | |
| 0 | 3 | 0 | 3 | -34.32 | 328.27 | -33.45 | 144.35 | 0.7834 | |
| 6 | 22 | 5 | 17 | -34.54 | 327.70 | -34.01 | 144.13 | 0.7886 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
