| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 47 | 262 | 33 | 186 | -34.24 | 330.40 | -21.88 | 154.53 | 0.7152 | |
|
previous
or next day for the same group /
back to the solar disc Gyula 2000-08-07 07:44:43 UT ![]() |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 22 | 139 | 15 | 95 | -33.49 | 333.40 | -18.88 | 156.95 | 0.6916 | |
| 1 | 3 | 0 | 2 | -34.14 | 332.28 | -20.00 | 156.22 | 0.7042 | |
| 0 | 0 | 0 | 0 | -36.41 | 330.24 | -22.04 | 155.76 | 0.7381 | |
| 0 | 2 | 0 | 2 | -36.37 | 329.97 | -22.32 | 155.47 | 0.7391 | |
| 0 | 118 | 0 | 87 | -35.33 | 328.13 | -24.15 | 153.02 | 0.7380 | |
| 24 | -5 | 18 | -5 | -35.22 | 327.42 | -24.87 | 152.27 | 0.7408 | |
| -6 | -5 | -6 | -5 | -34.95 | 327.23 | -25.04 | 151.91 | 0.7392 | |
| -6 | -5 | -6 | -5 | -35.10 | 326.96 | -25.33 | 151.77 | 0.7422 | |
| -6 | -5 | -6 | -5 | -34.75 | 326.70 | -25.58 | 151.27 | 0.7402 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
