Gyula 2000-08-10 10:06:45 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 7 | 45 | 6 | 40 | -12.25 | 4.96 | 53.66 | 250.68 | 0.8358 | |
|
previous
or next day for the same group /
back to the solar disc Gyula 2000-08-10 10:06:45 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 3 | 17 | 3 | 16 | -11.97 | 7.37 | 56.06 | 251.79 | 0.8565 | |
| 2 | 12 | 2 | 10 | -11.62 | 4.37 | 53.07 | 251.24 | 0.8290 | |
| 0 | 4 | 0 | 3 | -13.46 | 3.05 | 51.74 | 248.64 | 0.8221 | |
| 2 | 10 | 1 | 9 | -12.94 | 2.76 | 51.45 | 249.14 | 0.8178 | |
| 0 | 2 | 0 | 2 | -12.64 | 1.48 | 50.19 | 249.03 | 0.8049 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
