Gyula 2000-08-15 13:28:14 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 41 | 350 | 27 | 229 | -5.87 | 204.61 | -38.75 | 107.13 | 0.6537 | |
|
previous
or next day for the same group /
back to the solar disc Gyula 2000-08-15 13:28:14 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 1 | 2 | 0 | 2 | -3.94 | 206.12 | -37.24 | 104.91 | 0.6270 | |
| 34 | 326 | 22 | 212 | -6.09 | 204.89 | -38.47 | 107.58 | 0.6512 | |
| -2 | -2 | -2 | -2 | -5.90 | 204.68 | -38.68 | 107.21 | 0.6531 | |
| -2 | -2 | -2 | -2 | -5.44 | 204.83 | -38.53 | 106.59 | 0.6493 | |
| 0 | 6 | 0 | 4 | -7.87 | 202.83 | -40.53 | 109.16 | 0.6838 | |
| 0 | 1 | 0 | 1 | -7.55 | 202.64 | -40.72 | 108.62 | 0.6847 | |
| 5 | 12 | 4 | 8 | -6.76 | 201.29 | -42.07 | 106.94 | 0.6979 | |
| 1 | 3 | 1 | 2 | -6.05 | 201.21 | -42.15 | 105.93 | 0.6963 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
