Gyula 2000-08-18 15:02:15 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 58 | 322 | 30 | 165 | 12.68 | 200.04 | -2.80 | 25.12 | 0.1129 | |
|
previous
or next day for the same group /
back to the solar disc Gyula 2000-08-18 15:02:15 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 0 | 1 | 0 | 1 | 8.42 | 223.83 | 21.00 | 275.76 | 0.3578 | |
| 0 | 3 | 0 | 2 | 10.72 | 224.44 | 21.62 | 281.89 | 0.3715 | |
| 0 | 1 | 0 | 1 | 8.35 | 223.27 | 20.42 | 275.64 | 0.3485 | |
| 1 | 38 | 1 | 20 | 11.37 | 224.44 | 21.60 | 283.62 | 0.3729 | |
| 0 | 1 | 0 | 1 | 10.72 | 224.05 | 21.23 | 282.06 | 0.3653 | |
| 0 | 12 | 0 | 6 | 10.59 | 223.90 | 21.05 | 281.77 | 0.3623 | |
| 2 | -4 | 1 | -4 | 11.15 | 224.14 | 21.29 | 283.18 | 0.3675 | |
| 0 | 3 | 0 | 1 | 12.00 | 224.38 | 21.54 | 285.33 | 0.3740 | |
| 2 | -4 | 1 | -4 | 11.12 | 223.69 | 20.85 | 283.32 | 0.3604 | |
| 0 | 2 | 0 | 1 | 10.86 | 220.32 | 17.47 | 284.43 | 0.3058 | |
| 0 | 1 | 0 | 1 | 10.98 | 220.15 | 17.31 | 284.92 | 0.3036 | |
| 0 | 1 | 0 | 1 | 11.30 | 218.59 | 15.77 | 287.22 | 0.2802 | |
| 0 | 2 | 0 | 1 | 16.90 | 220.35 | 17.53 | 302.03 | 0.3414 | |
| 0 | 1 | 0 | 0 | 11.13 | 217.68 | 14.85 | 287.47 | 0.2649 | |
| 1 | 11 | 1 | 6 | 11.03 | 217.41 | 14.56 | 287.36 | 0.2597 | |
| 0 | 6 | 0 | 3 | 10.79 | 216.62 | 13.78 | 287.24 | 0.2461 | |
| 0 | 3 | 0 | 1 | 16.05 | 195.42 | -7.40 | 37.50 | 0.2043 | |
| 52 | 233 | 26 | 118 | 13.24 | 191.65 | -11.18 | 58.87 | 0.2215 | |
| 0 | 1 | 0 | 0 | 15.64 | 189.78 | -13.04 | 54.27 | 0.2689 | |
| 0 | 2 | 0 | 1 | 16.00 | 189.59 | -13.24 | 53.55 | 0.2749 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
