| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 24 | 205 | 34 | 305 | -18.18 | 47.28 | -66.90 | 112.17 | 0.9443 | |
|
previous
or next day for the same group /
back to the solar disc Gyula 2000-08-25 08:04:34 UT ![]() |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 14 | 139 | 19 | 192 | -19.18 | 49.57 | -64.61 | 113.77 | 0.9339 | |
| -1 | -1 | -1 | -1 | -18.89 | 49.26 | -64.92 | 113.38 | 0.9351 | |
| 3 | -1 | 4 | -1 | -18.74 | 48.73 | -65.44 | 113.09 | 0.9378 | |
| 1 | -1 | 1 | -1 | -18.43 | 48.86 | -65.32 | 112.81 | 0.9366 | |
| 0 | 4 | 0 | 6 | -18.43 | 45.63 | -68.55 | 111.98 | 0.9535 | |
| 0 | 1 | 0 | 1 | -17.69 | 46.11 | -68.05 | 111.35 | 0.9501 | |
| 0 | 0 | 0 | 0 | -18.35 | 44.75 | -69.42 | 111.69 | 0.9575 | |
| 6 | 61 | 10 | 106 | -16.76 | 43.76 | -70.41 | 109.85 | 0.9603 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
