Gyula 2000-09-07 06:04:36 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 0 | 19 | 0 | 11 | 13.53 | 330.71 | 27.14 | 285.60 | 0.4623 | |
|
previous
or next day for the same group /
back to the solar disc Gyula 2000-09-07 06:04:36 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 0 | 3 | 0 | 2 | 13.54 | 335.67 | 32.10 | 283.95 | 0.5345 | |
| 0 | 2 | 0 | 1 | 14.20 | 331.42 | 27.85 | 286.62 | 0.4745 | |
| 0 | 11 | 0 | 6 | 12.65 | 329.72 | 26.15 | 283.94 | 0.4450 | |
| 0 | 3 | 0 | 2 | 15.84 | 328.37 | 24.80 | 291.70 | 0.4361 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
