Debrecen 2000-09-16 06:57:10 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 87 | 504 | 87 | 519 | -12.86 | 125.93 | -58.29 | 108.99 | 0.8783 | |
|
previous
or next day for the same group /
back to the solar disc Debrecen 2000-09-16 06:57:10 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 45 | 270 | 43 | 264 | -13.71 | 128.54 | -55.69 | 110.72 | 0.8600 | |
| -1 | -1 | -1 | -1 | -13.35 | 128.21 | -56.01 | 110.22 | 0.8617 | |
| 10 | -1 | 10 | -1 | -14.21 | 127.22 | -57.01 | 110.84 | 0.8720 | |
| 5 | -1 | 5 | -1 | -14.10 | 126.72 | -57.51 | 110.56 | 0.8757 | |
| 0 | 1 | 0 | 1 | -15.06 | 125.06 | -59.12 | 111.09 | 0.8902 | |
| 1 | 18 | 1 | 20 | -15.34 | 124.51 | -59.72 | 111.22 | 0.8952 | |
| 2 | 33 | 2 | 30 | -9.73 | 129.16 | -55.07 | 106.43 | 0.8445 | |
| 1 | -7 | 1 | -7 | -9.44 | 129.20 | -54.98 | 106.12 | 0.8431 | |
| 0 | 19 | 0 | 22 | -14.85 | 122.58 | -61.60 | 110.13 | 0.9074 | |
| 2 | 11 | 2 | 12 | -12.27 | 125.16 | -59.07 | 108.08 | 0.8837 | |
| 0 | 2 | 0 | 2 | -14.16 | 122.77 | -61.41 | 109.45 | 0.9047 | |
| 0 | 2 | 0 | 2 | -10.45 | 126.40 | -57.81 | 106.44 | 0.8697 | |
| 0 | 2 | 0 | 2 | -9.05 | 127.55 | -56.66 | 105.19 | 0.8570 | |
| 0 | 1 | 0 | 1 | -14.63 | 121.59 | -62.59 | 109.62 | 0.9137 | |
| 1 | 55 | 1 | 63 | -13.29 | 122.91 | -61.27 | 108.56 | 0.9021 | |
| 1 | -15 | 1 | -15 | -13.15 | 122.28 | -61.95 | 108.22 | 0.9066 | |
| 0 | 1 | 0 | 1 | -9.54 | 125.18 | -59.01 | 105.09 | 0.8775 | |
| 0 | 1 | 0 | 1 | -13.27 | 121.08 | -63.10 | 108.04 | 0.9146 | |
| 0 | 1 | 0 | 1 | -13.10 | 121.05 | -63.13 | 107.86 | 0.9145 | |
| 19 | 84 | 21 | 94 | -10.51 | 122.74 | -61.49 | 105.50 | 0.8984 | |
| 0 | 3 | 0 | 3 | -11.19 | 121.71 | -62.48 | 105.98 | 0.9067 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
