Kanzelhoehe 2000-09-23 07:01:25 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 14 | 89 | 20 | 141 | -14.35 | 22.79 | -69.00 | 107.69 | 0.9495 | |
|
previous
or next day for the same group /
back to the solar disc Kanzelhoehe 2000-09-23 07:01:25 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 14 | 75 | 20 | 110 | -13.67 | 24.19 | -67.60 | 107.29 | 0.9424 | |
| 0 | 12 | 0 | 27 | -16.89 | 17.64 | -74.14 | 109.19 | 0.9756 | |
| 0 | 2 | 0 | 4 | -15.98 | 19.10 | -72.68 | 108.56 | 0.9693 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
