Debrecen 2000-09-30 12:34:06 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 47 | 292 | 35 | 224 | -21.63 | 314.39 | -42.01 | 125.73 | 0.7683 | |
|
previous
or next day for the same group /
back to the solar disc Debrecen 2000-09-30 12:34:06 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 22 | 128 | 16 | 96 | -21.75 | 316.14 | -40.26 | 126.92 | 0.7531 | |
| 1 | -1 | 0 | -1 | -21.33 | 315.52 | -40.88 | 126.05 | 0.7563 | |
| 0 | 1 | 0 | 1 | -20.61 | 315.57 | -40.83 | 125.26 | 0.7517 | |
| 16 | 89 | 12 | 69 | -21.92 | 314.05 | -42.35 | 125.82 | 0.7730 | |
| 0 | 2 | 0 | 1 | -23.28 | 311.92 | -44.47 | 126.10 | 0.7987 | |
| 0 | 2 | 0 | 2 | -20.08 | 314.60 | -41.80 | 124.05 | 0.7578 | |
| 0 | 2 | 0 | 2 | -20.37 | 314.13 | -42.27 | 124.10 | 0.7637 | |
| 0 | 17 | 0 | 13 | -22.25 | 312.08 | -44.32 | 125.04 | 0.7921 | |
| 0 | 1 | 0 | 1 | -22.59 | 311.73 | -44.67 | 125.23 | 0.7969 | |
| 0 | -8 | 0 | -8 | -21.92 | 312.02 | -44.38 | 124.64 | 0.7909 | |
| 0 | 2 | 0 | 1 | -20.08 | 313.61 | -42.79 | 123.46 | 0.7670 | |
| 0 | 1 | 0 | 1 | -22.86 | 311.02 | -45.38 | 125.14 | 0.8042 | |
| 0 | 2 | 0 | 2 | -19.79 | 313.80 | -42.60 | 123.23 | 0.7638 | |
| 0 | 1 | 0 | 1 | -22.38 | 310.92 | -45.48 | 124.56 | 0.8028 | |
| 3 | 20 | 2 | 15 | -20.46 | 312.53 | -43.87 | 123.28 | 0.7790 | |
| 3 | 10 | 3 | 8 | -21.97 | 310.02 | -46.38 | 123.63 | 0.8085 | |
| 0 | 1 | 0 | 1 | -21.21 | 310.41 | -45.99 | 122.98 | 0.8015 | |
| 2 | 13 | 2 | 10 | -20.33 | 311.11 | -45.29 | 122.36 | 0.7912 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
