Kanzelhoehe 2000-10-02 10:17:28 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 100 | 814 | 60 | 478 | -21.60 | 314.94 | -16.29 | 151.16 | 0.5398 | |
|
previous
or next day for the same group /
back to the solar disc Kanzelhoehe 2000-10-02 10:17:28 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 0 | 5 | 0 | 3 | -21.17 | 319.73 | -11.51 | 158.17 | 0.5022 | |
| 52 | 425 | 30 | 246 | -21.51 | 317.91 | -13.32 | 155.43 | 0.5175 | |
| 3 | -2 | 2 | -2 | -21.78 | 317.17 | -14.06 | 154.48 | 0.5258 | |
| 3 | -2 | 2 | -2 | -21.95 | 316.63 | -14.60 | 153.79 | 0.5315 | |
| 1 | -2 | 0 | -2 | -21.77 | 316.66 | -14.57 | 153.67 | 0.5290 | |
| 0 | 1 | 0 | 0 | -20.81 | 316.68 | -14.55 | 152.83 | 0.5162 | |
| 0 | 2 | 0 | 1 | -21.29 | 316.27 | -14.96 | 152.63 | 0.5252 | |
| 0 | 5 | 0 | 3 | -20.76 | 316.01 | -15.22 | 151.72 | 0.5203 | |
| 0 | 3 | 0 | 2 | -21.16 | 315.76 | -15.47 | 151.71 | 0.5271 | |
| 0 | 2 | 0 | 1 | -22.23 | 314.55 | -16.69 | 150.93 | 0.5493 | |
| 13 | 68 | 8 | 40 | -21.54 | 313.66 | -17.58 | 148.98 | 0.5472 | |
| 0 | 7 | 0 | 4 | -20.86 | 313.97 | -17.26 | 148.74 | 0.5364 | |
| 0 | 1 | 0 | 1 | -20.42 | 313.81 | -17.42 | 148.05 | 0.5323 | |
| 6 | 281 | 4 | 168 | -21.01 | 312.41 | -18.82 | 146.69 | 0.5505 | |
| 16 | -14 | 10 | -14 | -21.93 | 311.73 | -19.51 | 146.72 | 0.5667 | |
| -15 | -14 | -15 | -14 | -22.18 | 311.45 | -19.78 | 146.62 | 0.5718 | |
| 0 | 1 | 0 | 0 | -20.68 | 311.33 | -19.91 | 144.84 | 0.5554 | |
| 0 | 3 | 0 | 2 | -23.04 | 309.61 | -21.62 | 145.18 | 0.5961 | |
| 1 | -14 | 1 | -14 | -20.86 | 310.92 | -20.31 | 144.51 | 0.5609 | |
| 5 | -14 | 3 | -14 | -21.33 | 310.36 | -20.87 | 144.31 | 0.5709 | |
| 0 | 3 | 0 | 2 | -23.25 | 305.02 | -26.21 | 140.21 | 0.6364 | |
| 0 | 5 | 0 | 3 | -22.64 | 305.19 | -26.04 | 139.72 | 0.6290 | |
| 0 | 2 | 0 | 2 | -24.93 | 301.18 | -30.05 | 138.28 | 0.6847 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
