| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 152 | 946 | 134 | 830 | 3.02 | 256.54 | 55.69 | 269.53 | 0.8260 | |
|
previous
or next day for the same group /
back to the solar disc Debrecen 2000-10-12 07:29:14 UT ![]() |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 40 | 262 | 40 | 258 | 2.12 | 260.73 | 59.88 | 268.94 | 0.8666 | |
| 2 | -1 | 2 | -1 | 3.25 | 261.37 | 60.53 | 270.31 | 0.8712 | |
| 0 | 3 | 0 | 2 | 0.93 | 258.77 | 57.91 | 267.32 | 0.8501 | |
| 9 | 22 | 8 | 20 | 4.15 | 258.34 | 57.49 | 271.06 | 0.8433 | |
| 5 | 658 | 4 | 549 | 3.16 | 256.38 | 55.54 | 269.68 | 0.8255 | |
| 0 | 1 | 0 | 1 | 4.51 | 257.71 | 56.85 | 271.43 | 0.8370 | |
| 26 | -5 | 22 | -5 | 1.83 | 253.71 | 52.85 | 267.72 | 0.7996 | |
| 60 | -5 | 50 | -5 | 3.99 | 255.15 | 54.29 | 270.56 | 0.8123 | |
| 10 | -5 | 8 | -5 | 3.48 | 253.73 | 52.88 | 269.78 | 0.7981 | |
| -8 | -5 | -8 | -5 | 4.12 | 254.44 | 53.59 | 270.66 | 0.8050 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
