Gyula 2000-10-29 14:07:53 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 21 | 127 | 10 | 67 | -12.38 | 328.44 | -4.55 | 166.36 | 0.3067 | |
|
previous
or next day for the same group /
back to the solar disc Gyula 2000-10-29 14:07:53 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 0 | 4 | 0 | 2 | -10.26 | 336.00 | 3.03 | 191.47 | 0.2625 | |
| 0 | 5 | 0 | 3 | -11.36 | 335.45 | 2.48 | 188.78 | 0.2792 | |
| 0 | 3 | 0 | 2 | -17.35 | 331.56 | -1.44 | 176.32 | 0.3760 | |
| 0 | 3 | 0 | 2 | -15.75 | 331.16 | -1.84 | 174.91 | 0.3503 | |
| 20 | 54 | 10 | 27 | -9.28 | 330.48 | -2.50 | 169.83 | 0.2444 | |
| -5 | -5 | -5 | -5 | -9.04 | 330.50 | -2.50 | 169.65 | 0.2405 | |
| -5 | -5 | -5 | -5 | -9.09 | 330.30 | -2.70 | 168.86 | 0.2419 | |
| 0 | 6 | 0 | 3 | -17.20 | 325.92 | -7.08 | 162.38 | 0.3905 | |
| 0 | 6 | 0 | 3 | -15.19 | 326.72 | -6.26 | 162.70 | 0.3554 | |
| 0 | 1 | 0 | 1 | -15.59 | 326.13 | -6.85 | 161.56 | 0.3646 | |
| 1 | 23 | 0 | 12 | -15.97 | 325.43 | -7.55 | 160.18 | 0.3741 | |
| 0 | 8 | 0 | 4 | -14.81 | 325.81 | -7.17 | 160.00 | 0.3543 | |
| 0 | 5 | 0 | 3 | -8.97 | 328.42 | -4.56 | 161.48 | 0.2481 | |
| 0 | 3 | 0 | 2 | -14.76 | 324.60 | -8.40 | 156.85 | 0.3609 | |
| 0 | 4 | 0 | 2 | -14.59 | 317.93 | -15.05 | 142.36 | 0.4133 | |
| 0 | 2 | 0 | 1 | -12.46 | 317.38 | -15.63 | 137.82 | 0.3934 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
