Gyula 2000-11-06 07:39:13 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 14 | 82 | 18 | 115 | -16.74 | 163.95 | -67.08 | 109.49 | 0.9372 | |
|
previous
or next day for the same group /
back to the solar disc Gyula 2000-11-06 07:39:13 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 5 | 82 | 6 | 115 | -16.93 | 164.14 | -66.89 | 109.72 | 0.9363 | |
| 2 | -1 | 3 | -1 | -16.66 | 164.10 | -66.93 | 109.43 | 0.9362 | |
| 7 | -1 | 9 | -1 | -16.64 | 163.78 | -67.26 | 109.35 | 0.9381 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
