| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 13 | 55 | 9 | 41 | -21.05 | 218.46 | 42.46 | 237.66 | 0.7477 | |
|
next day for the same group /
back to the solar disc Gyula 2000-11-10 11:49:11 UT ![]() |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 6 | 41 | 4 | 31 | -21.22 | 219.26 | 43.26 | 237.90 | 0.7564 | |
| 4 | -1 | 3 | -1 | -20.84 | 219.25 | 43.25 | 238.36 | 0.7545 | |
| 0 | 1 | 0 | 1 | -21.38 | 218.50 | 42.50 | 237.31 | 0.7498 | |
| 1 | 6 | 1 | 4 | -20.59 | 216.53 | 40.52 | 237.18 | 0.7262 | |
| 1 | -4 | 1 | -4 | -20.56 | 216.28 | 40.27 | 237.07 | 0.7235 | |
| 0 | 2 | 0 | 1 | -20.79 | 215.95 | 39.95 | 236.59 | 0.7215 | |
| 0 | 2 | 0 | 1 | -20.77 | 215.68 | 39.68 | 236.46 | 0.7186 | |
| 0 | 1 | 0 | 1 | -21.29 | 215.08 | 39.07 | 235.45 | 0.7154 | |
| 1 | 2 | 0 | 2 | -21.89 | 214.64 | 38.64 | 234.43 | 0.7147 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
