Gyula 2000-12-19 07:27:54 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 0 | 12 | 0 | 11 | 7.38 | 323.38 | -61.04 | 80.80 | 0.8795 | |
|
previous
or next day for the same group /
back to the solar disc Gyula 2000-12-19 07:27:54 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 0 | 2 | 0 | 1 | 5.20 | 329.01 | -55.41 | 82.68 | 0.8288 | |
| 0 | 1 | 0 | 1 | 5.97 | 328.92 | -55.51 | 81.76 | 0.8305 | |
| 0 | 1 | 0 | 1 | 5.21 | 328.15 | -56.26 | 82.75 | 0.8370 | |
| 0 | 0 | 0 | 0 | 6.90 | 325.44 | -58.99 | 81.09 | 0.8634 | |
| 0 | 1 | 0 | 1 | 7.76 | 321.67 | -62.76 | 80.54 | 0.8950 | |
| 0 | 4 | 0 | 4 | 8.17 | 321.63 | -62.80 | 80.08 | 0.8956 | |
| 0 | 1 | 0 | 1 | 7.91 | 321.04 | -63.39 | 80.44 | 0.8999 | |
| 0 | 2 | 0 | 2 | 8.25 | 320.75 | -63.68 | 80.10 | 0.9023 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
