Gyula 2000-12-24 12:01:17 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 36 | 274 | 19 | 141 | -9.98 | 330.30 | 14.23 | 238.29 | 0.2866 | |
|
previous
or next day for the same group /
back to the solar disc Gyula 2000-12-24 12:01:17 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 0 | 1 | 0 | 1 | -8.93 | 333.05 | 16.99 | 247.44 | 0.3139 | |
| 36 | 253 | 19 | 131 | -9.81 | 331.34 | 15.28 | 242.56 | 0.2938 | |
| 0 | 1 | 0 | 1 | -12.95 | 326.86 | 10.79 | 224.12 | 0.2633 | |
| 0 | 1 | 0 | 0 | -13.27 | 324.97 | 8.89 | 217.86 | 0.2462 | |
| 0 | 0 | 0 | 0 | -13.36 | 323.93 | 7.85 | 214.30 | 0.2371 | |
| 0 | 2 | 0 | 1 | -12.81 | 322.86 | 6.80 | 211.91 | 0.2193 | |
| 0 | 2 | 0 | 1 | -12.03 | 321.59 | 5.52 | 208.68 | 0.1969 | |
| 0 | 1 | 0 | 0 | -12.20 | 320.57 | 4.50 | 203.67 | 0.1917 | |
| 0 | 1 | 0 | 1 | -10.78 | 317.40 | 1.33 | 188.61 | 0.1526 | |
| 0 | 2 | 0 | 1 | -11.13 | 316.26 | 0.18 | 181.16 | 0.1569 | |
| 0 | 1 | 0 | 0 | -11.50 | 316.02 | -0.05 | 179.71 | 0.1633 | |
| 0 | 2 | 0 | 1 | -11.20 | 315.87 | -0.21 | 178.69 | 0.1582 | |
| 0 | 1 | 0 | 0 | -9.95 | 313.85 | -2.23 | 164.27 | 0.1418 | |
| 0 | 3 | 0 | 1 | -10.52 | 313.07 | -3.01 | 160.52 | 0.1554 | |
| 0 | 1 | 0 | 1 | -14.88 | 310.71 | -5.37 | 157.71 | 0.2395 | |
| 0 | 2 | 0 | 1 | -13.01 | 308.12 | -7.96 | 144.48 | 0.2332 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
