| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 38 | 239 | 35 | 222 | -28.16 | 54.62 | 55.04 | 238.49 | 0.8488 | |
|
previous
or next day for the same group /
back to the solar disc SOHO/MDI 2010-01-03 12:13:32 UT ![]() |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r |
| 3 | 119 | 3 | 117 | -27.76 | 57.42 | 57.83 | 239.69 | 0.8697 | |
| 5 | -1 | 5 | -1 | -27.45 | 56.83 | 57.25 | 239.91 | 0.8647 | |
| 7 | -1 | 7 | -1 | -28.08 | 57.03 | 57.45 | 239.25 | 0.8675 | |
| 0 | 6 | 0 | 6 | -27.98 | 55.37 | 55.78 | 238.94 | 0.8546 | |
| 0 | 2 | 0 | 2 | -27.54 | 54.72 | 55.14 | 239.28 | 0.8485 | |
| 2 | 11 | 2 | 10 | -27.86 | 53.24 | 53.65 | 238.50 | 0.8373 | |
| 0 | 3 | 0 | 2 | -27.56 | 52.30 | 52.72 | 238.57 | 0.8288 | |
| 0 | 2 | 0 | 2 | -26.96 | 51.47 | 51.89 | 239.03 | 0.8202 | |
| 16 | 69 | 14 | 60 | -28.70 | 51.80 | 52.22 | 237.11 | 0.8279 | |
| 0 | 7 | 0 | 6 | -29.16 | 51.13 | 51.55 | 236.36 | 0.8237 | |
| 5 | 20 | 4 | 17 | -28.84 | 50.35 | 50.77 | 236.47 | 0.8163 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
