SDO HMI 2010-08-11 02:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 17.15 | 37.30 | 10.95 | 23.86 | 14.23 | 300.89 | -39.21 | 75.37 | 0.6356 | -140.8 | 85.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2010-08-11 02:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 9.30 | 12.46 | 5.85 | 7.84 | 13.80 | 302.12 | -37.98 | 75.81 | 0.6187 | -818.2 | -432.4 | |
| 0.00 | 2.80 | 0.00 | 1.78 | 14.36 | 301.25 | -38.85 | 75.09 | 0.6312 | -736.0 | -541.4 | |
| 0.00 | 0.99 | 0.00 | 0.63 | 14.34 | 301.01 | -39.09 | 75.17 | 0.6343 | -427.0 | -375.5 | |
| 1.35 | 1.81 | 0.87 | 1.16 | 14.54 | 300.81 | -39.30 | 74.89 | 0.6373 | -641.1 | -633.6 | |
| 0.00 | 1.90 | 0.00 | 1.23 | 15.06 | 300.28 | -39.82 | 74.19 | 0.6450 | 646.0 | 476.4 | |
| 0.00 | 1.90 | 0.00 | 1.22 | 14.02 | 300.47 | -39.64 | 75.76 | 0.6408 | 724.0 | 537.2 | |
| 0.00 | 2.08 | 0.00 | 1.33 | 13.26 | 300.54 | -39.56 | 76.95 | 0.6387 | 686.0 | 520.3 | |
| 0.00 | 0.81 | 0.00 | 0.52 | 13.61 | 300.31 | -39.80 | 76.43 | 0.6422 | 563.0 | 519.8 | |
| 4.51 | 8.03 | 2.94 | 5.23 | 15.18 | 299.80 | -40.30 | 74.11 | 0.6513 | 587.4 | 418.6 | |
| 0.00 | 1.72 | 0.00 | 1.11 | 13.54 | 300.12 | -39.99 | 76.58 | 0.6446 | 560.0 | 472.6 | |
| 1.99 | 2.80 | 1.29 | 1.81 | 13.86 | 299.97 | -40.14 | 76.10 | 0.6470 | -717.0 | -641.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
