SDO HMI 2010-08-11 03:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 15.98 | 38.08 | 10.13 | 24.19 | 14.39 | 300.91 | -38.65 | 75.01 | 0.6284 | -136.4 | -74.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2010-08-11 03:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 9.21 | 13.00 | 5.75 | 8.11 | 13.87 | 302.19 | -37.36 | 75.56 | 0.6106 | -816.4 | -548.4 | |
| 0.00 | 4.06 | 0.00 | 2.57 | 14.33 | 301.27 | -38.29 | 75.01 | 0.6237 | -794.0 | -604.4 | |
| 0.00 | 1.53 | 0.00 | 0.97 | 14.50 | 300.95 | -38.60 | 74.82 | 0.6281 | -730.0 | -617.2 | |
| 0.00 | 0.63 | 0.00 | 0.40 | 14.65 | 300.92 | -38.64 | 74.58 | 0.6289 | -435.0 | -419.0 | |
| 0.00 | 1.26 | 0.00 | 0.81 | 15.11 | 300.38 | -39.18 | 73.98 | 0.6368 | 605.0 | 432.6 | |
| 0.00 | 3.16 | 0.00 | 2.01 | 13.30 | 300.59 | -38.97 | 76.78 | 0.6309 | 627.0 | 629.9 | |
| 0.00 | 0.90 | 0.00 | 0.58 | 14.00 | 300.45 | -39.11 | 75.70 | 0.6338 | 597.0 | 474.0 | |
| 6.77 | 12.37 | 4.38 | 7.99 | 15.19 | 299.74 | -39.81 | 74.00 | 0.6451 | 726.5 | 308.1 | |
| 0.00 | 1.17 | 0.00 | 0.75 | 13.81 | 299.96 | -39.60 | 76.09 | 0.6399 | -694.0 | -566.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
