SDO HMI 2010-08-11 11:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 26.18 | 40.62 | 15.68 | 24.33 | 14.41 | 301.36 | -33.81 | 73.75 | 0.5633 | -21.0 | 6.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2010-08-11 11:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 11.92 | 15.62 | 7.01 | 9.19 | 14.06 | 302.86 | -32.31 | 73.92 | 0.5416 | -824.5 | -554.9 | |
| 3.70 | 7.76 | 2.21 | 4.63 | 14.27 | 301.71 | -33.46 | 73.90 | 0.5583 | -846.4 | -555.6 | |
| 0.00 | 1.35 | 0.00 | 0.82 | 13.78 | 300.77 | -34.40 | 75.02 | 0.5702 | 692.0 | 587.2 | |
| 0.00 | 1.81 | 0.00 | 1.09 | 13.41 | 300.68 | -34.49 | 75.70 | 0.5706 | 643.0 | 541.0 | |
| 0.00 | 0.63 | 0.00 | 0.38 | 13.55 | 300.58 | -34.59 | 75.46 | 0.5723 | 622.0 | 480.6 | |
| 10.56 | 13.45 | 6.46 | 8.22 | 15.13 | 299.68 | -35.49 | 73.01 | 0.5882 | 820.7 | 774.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
