SDO HMI 2010-08-12 09:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 30.69 | 58.48 | 16.34 | 31.21 | 14.17 | 302.30 | -20.75 | 67.65 | 0.3727 | -119.4 | -220.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2010-08-12 09:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 6.77 | 8.48 | 3.56 | 4.46 | 14.15 | 304.72 | -18.33 | 65.54 | 0.3365 | -978.9 | -701.3 | |
| 1.44 | 29.88 | 0.77 | 15.87 | 14.04 | 303.23 | -19.82 | 67.28 | 0.3581 | -1146.7 | -873.8 | |
| 3.25 | -2.00 | 1.73 | -2.00 | 14.43 | 303.13 | -19.92 | 66.33 | 0.3618 | -761.4 | 999999 | |
| 1.99 | -2.00 | 1.05 | -2.00 | 13.96 | 302.97 | -20.08 | 67.70 | 0.3616 | -937.7 | 999999 | |
| 8.85 | -2.00 | 4.70 | -2.00 | 14.17 | 302.82 | -20.23 | 67.28 | 0.3650 | -835.1 | 999999 | |
| 0.00 | 1.26 | 0.00 | 0.68 | 14.70 | 300.51 | -22.54 | 67.85 | 0.4020 | 634.0 | 447.4 | |
| 7.13 | 11.10 | 3.84 | 5.99 | 13.62 | 300.59 | -22.46 | 70.37 | 0.3959 | 979.1 | 703.9 | |
| 0.00 | 1.26 | 0.00 | 0.68 | 14.39 | 300.47 | -22.58 | 68.61 | 0.4011 | 862.0 | 687.1 | |
| 0.00 | 0.99 | 0.00 | 0.54 | 14.74 | 300.20 | -22.85 | 67.96 | 0.4069 | 857.0 | 678.0 | |
| 0.00 | 1.81 | 0.00 | 0.98 | 15.11 | 300.02 | -23.03 | 67.25 | 0.4113 | 851.0 | 746.7 | |
| 0.00 | 1.35 | 0.00 | 0.73 | 14.64 | 300.04 | -23.01 | 68.31 | 0.4088 | 577.0 | 332.5 | |
| 1.26 | 2.35 | 0.69 | 1.28 | 14.95 | 299.87 | -23.18 | 67.73 | 0.4127 | 734.1 | 663.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
