SDO HMI 2010-08-12 12:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 21.02 | 51.25 | 11.06 | 27.05 | 14.19 | 302.47 | -18.93 | 65.89 | 0.3457 | -198.8 | -126.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2010-08-12 12:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 7.22 | 8.12 | 3.76 | 4.23 | 14.17 | 304.90 | -16.50 | 63.35 | 0.3094 | -975.1 | -730.5 | |
| 4.51 | 24.63 | 2.37 | 12.94 | 14.12 | 303.36 | -18.03 | 65.29 | 0.3319 | -1093.4 | -802.7 | |
| 1.80 | -2.00 | 0.95 | -2.00 | 14.43 | 303.24 | -18.16 | 64.58 | 0.3356 | -749.7 | 999999 | |
| 2.35 | -2.00 | 1.23 | -2.00 | 13.99 | 303.18 | -18.22 | 65.85 | 0.3339 | -1022.3 | 999999 | |
| 0.00 | 1.62 | 0.00 | 0.86 | 13.82 | 300.94 | -20.46 | 68.40 | 0.3667 | 792.0 | 638.5 | |
| 0.00 | 2.08 | 0.00 | 1.11 | 13.57 | 300.69 | -20.71 | 69.25 | 0.3691 | 906.0 | 818.0 | |
| 0.00 | 0.99 | 0.00 | 0.53 | 14.66 | 300.45 | -20.95 | 66.65 | 0.3783 | 666.0 | 561.0 | |
| 2.26 | 6.68 | 1.20 | 3.56 | 13.74 | 300.41 | -20.99 | 69.03 | 0.3742 | 791.1 | 806.7 | |
| 0.00 | 1.08 | 0.00 | 0.58 | 14.78 | 300.27 | -21.13 | 66.52 | 0.3816 | 771.0 | 618.0 | |
| 1.26 | 6.05 | 0.68 | 3.24 | 15.14 | 300.07 | -21.33 | 65.81 | 0.3866 | 715.4 | 616.1 | |
| 1.62 | -10.00 | 0.87 | -10.00 | 14.95 | 299.99 | -21.41 | 66.33 | 0.3868 | 761.1 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
