SDO HMI 2010-08-12 23:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 10.28 | 42.93 | 5.23 | 22.00 | 14.16 | 302.46 | -12.86 | 57.43 | 0.2565 | -307.3 | 40.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2010-08-12 23:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 3.70 | 4.96 | 1.87 | 2.51 | 14.08 | 305.56 | -9.75 | 51.04 | 0.2123 | -1090.7 | -765.9 | |
| 0.00 | 3.79 | 0.00 | 1.93 | 14.17 | 304.12 | -11.19 | 54.34 | 0.2326 | -921.0 | -713.3 | |
| 6.58 | 17.05 | 3.36 | 8.69 | 14.19 | 303.55 | -11.77 | 55.57 | 0.2408 | -1014.5 | -818.6 | |
| 0.00 | 4.51 | 0.00 | 2.34 | 15.03 | 300.33 | -14.98 | 58.76 | 0.2933 | 491.0 | 687.9 | |
| 0.00 | 4.96 | 0.00 | 2.56 | 13.61 | 300.20 | -15.11 | 63.36 | 0.2847 | 1054.0 | 869.4 | |
| 0.00 | 6.58 | 0.00 | 3.41 | 14.07 | 300.08 | -15.24 | 62.09 | 0.2898 | 927.0 | 806.5 | |
| 0.00 | 1.08 | 0.00 | 0.56 | 13.47 | 299.53 | -15.78 | 64.71 | 0.2938 | 754.0 | 581.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
