groupProj. UProj. WSCorr. UCorr. WS BLLCMPos. angler MU MP

11124 142.96 650.77 95.46 435.05 13.73 172.59 40.97 287.92 0.6703 -82.3 -3.4


previous   or   next   observation for the same group / back to the solar disc

SDO HMI 2010-11-16 17:58:57 UT
No observation available
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)


spotProj. UProj. WSCorr. UCorr. WSBLLCMPos. angler MU MP

1 68.69 349.78 48.33 245.88 12.81 176.24 44.62 285.44 0.7129 -1070.6 -292.7
2 4.04 -1.00 2.78 -1.00 12.64 174.97 43.35 285.48 0.6974 -873.7 999999
3 4.55 -1.00 3.12 -1.00 12.56 174.62 43.00 285.45 0.6929 -930.8 999999
4 0.00 1.63 0.00 1.10 12.71 173.70 42.08 285.88 0.6820 -618.0 -549.2
5 0.00 3.69 0.00 2.46 11.98 172.86 41.24 285.02 0.6700 -788.0 -627.3
6 0.00 0.94 0.00 0.63 13.07 172.91 41.29 286.60 0.6731 286.0 194.6
7 0.00 4.98 0.00 3.30 13.23 172.34 40.72 287.01 0.6664 705.0 478.9
8 0.00 1.03 0.00 0.67 13.03 171.18 39.56 287.03 0.6513 567.0 390.0
9 0.00 0.94 0.00 0.62 15.76 171.25 39.63 291.09 0.6602 601.0 485.4
10 1.20 3.86 0.77 2.49 13.60 170.31 38.69 288.17 0.6418 -473.1 -31.6
11 0.34 -10.00 0.22 -10.00 13.81 170.31 38.69 288.49 0.6424 454.8 999999
12 1.29 1.46 0.83 0.94 13.75 170.14 38.52 288.47 0.6401 -756.6 -737.5
13 0.00 1.89 0.00 1.21 13.77 169.64 38.02 288.66 0.6337 -318.0 -347.2
14 0.00 0.77 0.00 0.49 14.34 169.60 37.98 289.56 0.6350 283.0 182.1
15 5.75 9.10 3.67 5.80 14.17 169.44 37.82 289.34 0.6325 659.2 629.0
16 0.00 1.89 0.00 1.21 14.90 169.36 37.74 290.50 0.6338 525.0 400.4
17 0.00 0.77 0.00 0.49 14.62 169.30 37.68 290.10 0.6322 556.0 493.6
18 0.00 1.20 0.00 0.78 16.72 169.72 38.10 293.11 0.6449 532.0 376.3
19 0.00 0.77 0.00 0.49 13.58 168.64 37.02 288.72 0.6202 501.0 348.2
20 6.44 263.06 4.07 164.66 14.83 168.53 36.91 290.72 0.6230 705.8 401.0
21 2.23 -20.00 1.41 -20.00 15.04 168.46 36.84 291.08 0.6229 675.2 999999
22 8.16 -20.00 5.13 -20.00 15.18 168.07 36.45 291.45 0.6183 982.4 999999
23 37.61 -20.00 23.48 -20.00 15.19 167.50 35.88 291.72 0.6111 1288.0 999999
24 0.69 -20.00 0.43 -20.00 15.62 167.39 35.77 292.44 0.6114 1061.6 999999
25 1.97 -20.00 1.22 -20.00 14.35 167.07 35.45 290.56 0.6024 826.9 999999
26 0.00 1.29 0.00 0.79 14.16 166.07 34.45 290.69 0.5885 835.0 699.7
27 0.00 1.72 0.00 1.04 14.42 165.45 33.83 291.40 0.5813 620.0 497.9


  		• Proj. U -  Projected umbra area in millionths of solar disc, negative values indicate
    that the umbra consists of fragmented regions which cannot be separated without losing umbral area.
    In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that
    the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2.
  		• Proj. WS -  Projected whole spot area in millionths of solar disc, negative values indicate
    that several umbras have a common penumbra, e.g. -7 means that the given umbra shares
    a penumbra with umbra No.7, and the WS value is indicated at No.7.
  		• Corr. U -  Corrected umbra area in millionths of solar hemisphere, for negative values see above
  		• Corr. WS -  Corrected whole spot area in millionths of solar hemisphere, for negative values see above
  		• B -  Heliographic latitude B; positive: North, negative: South
  		• L -  Heliographic longitude L
  		• LCM -  Longitudinal distance from the Sun's central meridian
  		• Pos. angle -  Position angle
  		• r -  Distance from the centre of Sun's disc in terms of Sun's radius
  		• MU -  Mean magnetic field within the umbra contour averaged the pixel values with sign.
  		• MP -  Mean magnetic field within the penumbra contour averaged the pixel values with sign.
