SDO HMI 2010-11-20 00:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 9.01 | 52.93 | 24.05 | 223.31 | 14.19 | 171.62 | 83.41 | 284.07 | 0.9905 | 244.0 | -63.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2010-11-20 00:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.86 | 0.00 | 13.67 | 12.41 | 176.96 | 88.75 | 282.35 | 0.9997 | -378.0 | -413.3 | |
| 0.00 | 6.09 | 0.00 | 87.09 | 13.41 | 176.31 | 88.10 | 283.34 | 0.9993 | -346.0 | -310.3 | |
| 2.32 | 45.98 | 6.51 | 122.55 | 14.91 | 168.29 | 80.08 | 284.75 | 0.9851 | -165.3 | 203.9 | |
| 6.69 | -3.00 | 17.54 | -3.00 | 14.95 | 167.46 | 79.25 | 284.78 | 0.9826 | 464.9 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
