SDO HMI 2011-01-01 09:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 60.07 | 193.45 | 39.21 | 126.58 | 34.05 | 267.56 | 17.67 | 337.32 | 0.6548 | -26.6 | -24.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-01-01 09:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 21.16 | 100.17 | 13.90 | 65.95 | 33.47 | 269.86 | 19.97 | 334.31 | 0.6595 | -1066.2 | -260.8 | |
| 2.72 | 3.23 | 1.77 | 2.11 | 33.44 | 268.69 | 18.80 | 335.58 | 0.6527 | -816.8 | -755.5 | |
| 1.78 | 8.16 | 1.17 | 5.34 | 33.85 | 268.48 | 18.59 | 336.11 | 0.6562 | -741.2 | -674.2 | |
| 0.00 | 1.19 | 0.00 | 0.75 | 31.66 | 266.31 | 16.41 | 337.03 | 0.6186 | 694.0 | 626.0 | |
| 3.48 | 4.76 | 2.28 | 3.11 | 34.52 | 266.83 | 16.94 | 338.44 | 0.6557 | -656.5 | -532.0 | |
| 0.00 | 1.78 | 0.00 | 1.17 | 34.85 | 266.64 | 16.75 | 338.88 | 0.6587 | -530.0 | -458.1 | |
| 1.70 | 3.65 | 1.08 | 2.32 | 33.19 | 264.51 | 14.62 | 340.29 | 0.6285 | 732.5 | 682.7 | |
| 0.00 | 1.27 | 0.00 | 0.83 | 34.67 | 264.74 | 14.84 | 340.95 | 0.6479 | 694.0 | 635.9 | |
| 9.94 | 31.18 | 6.51 | 20.39 | 35.42 | 264.80 | 14.91 | 341.33 | 0.6573 | 644.9 | 517.2 | |
| 5.86 | -9.00 | 3.82 | -9.00 | 35.16 | 264.49 | 14.60 | 341.53 | 0.6527 | 808.4 | 999999 | |
| 2.55 | 38.06 | 1.64 | 24.61 | 34.37 | 264.09 | 14.20 | 341.53 | 0.6413 | 990.8 | 529.3 | |
| 10.88 | -11.00 | 7.04 | -11.00 | 34.77 | 264.01 | 14.12 | 341.86 | 0.6460 | 986.5 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
