SDO HMI 2011-01-02 08:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 5.94 | 0.00 | 3.28 | -28.43 | 231.84 | -5.43 | 169.13 | 0.4377 | -94.0 | -412.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-01-02 08:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.93 | 0.00 | 0.51 | -27.60 | 234.98 | -2.29 | 175.11 | 0.4172 | 601.0 | 464.3 | |
| 0.00 | 0.76 | 0.00 | 0.41 | -26.43 | 233.82 | -3.45 | 172.24 | 0.4008 | 778.0 | 513.4 | |
| 0.00 | 3.23 | 0.00 | 1.79 | -28.85 | 230.90 | -6.37 | 167.39 | 0.4467 | -1047.0 | -852.6 | |
| 0.00 | 1.02 | 0.00 | 0.57 | -29.28 | 230.57 | -6.70 | 167.00 | 0.4542 | -708.0 | -486.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
