SDO HMI 2011-01-03 07:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 23.78 | 58.80 | 19.96 | 50.48 | 33.88 | 267.15 | 42.51 | 316.62 | 0.8179 | 100.5 | -146.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-01-03 07:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 7.48 | 32.46 | 6.70 | 29.11 | 32.95 | 270.43 | 45.79 | 313.77 | 0.8351 | -662.5 | -278.4 | |
| 0.00 | 1.19 | 0.00 | 0.99 | 34.00 | 265.15 | 40.51 | 317.81 | 0.8041 | -288.0 | -316.1 | |
| 0.00 | 1.10 | 0.00 | 0.88 | 33.00 | 263.81 | 39.17 | 317.63 | 0.7883 | 536.0 | 397.7 | |
| 1.44 | 3.06 | 1.20 | 2.54 | 35.12 | 264.39 | 39.75 | 319.39 | 0.8059 | -458.3 | -362.6 | |
| 0.00 | 0.34 | 0.00 | 0.28 | 34.63 | 263.23 | 38.59 | 319.64 | 0.7948 | 413.0 | 427.0 | |
| 3.48 | 3.74 | 2.84 | 3.04 | 34.89 | 263.14 | 38.50 | 319.95 | 0.7959 | 471.1 | 334.0 | |
| 5.35 | 6.97 | 4.34 | 5.65 | 35.42 | 262.33 | 37.69 | 321.00 | 0.7940 | 552.2 | 407.9 | |
| 2.46 | 3.57 | 2.03 | 2.93 | 36.07 | 262.65 | 38.01 | 321.42 | 0.8005 | 384.0 | 243.1 | |
| 0.51 | -8.00 | 0.42 | -8.00 | 35.95 | 262.54 | 37.90 | 321.38 | 0.7990 | -108.0 | 999999 | |
| 0.00 | 1.27 | 0.00 | 1.01 | 34.72 | 261.73 | 37.09 | 320.72 | 0.7852 | 632.0 | 485.8 | |
| 3.06 | 5.10 | 2.43 | 4.05 | 35.22 | 261.14 | 36.50 | 321.60 | 0.7846 | 758.5 | 540.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
