SDO HMI 2011-01-03 13:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 55.87 | 202.04 | 29.05 | 104.85 | -13.98 | 207.69 | -13.67 | 130.10 | 0.2998 | -144.4 | -1.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-01-03 13:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.53 | 0.00 | 0.78 | -15.18 | 211.89 | -9.47 | 142.51 | 0.2621 | -491.0 | -390.2 | |
| 0.00 | 1.87 | 0.00 | 0.96 | -15.44 | 211.23 | -10.13 | 141.30 | 0.2725 | 945.0 | 795.5 | |
| 20.89 | 85.95 | 10.72 | 44.08 | -14.42 | 210.97 | -10.39 | 138.02 | 0.2624 | 1225.5 | 561.2 | |
| 2.55 | -3.00 | 1.31 | -3.00 | -14.75 | 210.80 | -10.57 | 138.42 | 0.2684 | 910.0 | 999999 | |
| 0.00 | 1.61 | 0.00 | 0.83 | -13.52 | 208.94 | -12.43 | 130.60 | 0.2768 | 895.0 | 665.4 | |
| 0.00 | 2.72 | 0.00 | 1.41 | -14.62 | 207.94 | -13.42 | 131.44 | 0.3010 | -804.0 | -630.1 | |
| 0.00 | 2.55 | 0.00 | 1.32 | -14.13 | 207.28 | -14.08 | 128.86 | 0.3044 | 915.0 | 695.1 | |
| 0.00 | 0.93 | 0.00 | 0.48 | -12.61 | 207.34 | -14.02 | 124.72 | 0.2890 | 852.0 | 762.7 | |
| 0.00 | 2.21 | 0.00 | 1.14 | -12.37 | 207.20 | -14.16 | 123.75 | 0.2888 | 1015.0 | 792.2 | |
| 0.00 | 1.10 | 0.00 | 0.57 | -13.95 | 207.04 | -14.32 | 127.92 | 0.3057 | 752.0 | 531.2 | |
| 1.95 | 20.89 | 1.02 | 10.92 | -14.27 | 206.11 | -15.25 | 127.07 | 0.3210 | -865.2 | -749.4 | |
| 6.03 | -11.00 | 3.15 | -11.00 | -14.08 | 205.90 | -15.46 | 126.25 | 0.3221 | -1113.3 | 999999 | |
| 0.00 | 1.19 | 0.00 | 0.62 | -13.24 | 205.64 | -15.72 | 123.59 | 0.3180 | -866.0 | -644.7 | |
| 1.36 | 1.87 | 0.71 | 0.98 | -13.83 | 204.91 | -16.45 | 123.99 | 0.3332 | -937.1 | -746.7 | |
| 14.52 | 52.49 | 7.62 | 27.52 | -13.26 | 204.79 | -16.57 | 122.33 | 0.3300 | -1160.7 | -468.4 | |
| 1.95 | 11.55 | 1.03 | 6.08 | -13.91 | 204.65 | -16.71 | 123.82 | 0.3375 | -972.6 | -721.9 | |
| 6.62 | -16.00 | 3.49 | -16.00 | -13.94 | 204.39 | -16.97 | 123.50 | 0.3412 | -966.4 | 999999 | |
| 0.00 | 2.46 | 0.00 | 1.30 | -14.63 | 204.05 | -17.31 | 124.70 | 0.3517 | -879.0 | -666.7 | |
| 0.00 | 1.10 | 0.00 | 0.58 | -14.36 | 204.07 | -17.29 | 124.07 | 0.3491 | -782.0 | -678.4 | |
| 0.00 | 1.44 | 0.00 | 0.76 | -14.02 | 204.07 | -17.29 | 123.25 | 0.3464 | -776.0 | -702.0 | |
| 0.00 | 1.19 | 0.00 | 0.63 | -14.20 | 204.05 | -17.31 | 123.67 | 0.3481 | -741.0 | -596.9 | |
| 0.00 | 1.10 | 0.00 | 0.58 | -14.29 | 203.82 | -17.54 | 123.56 | 0.3520 | -782.0 | -581.8 | |
| 0.00 | 3.23 | 0.00 | 1.70 | -13.63 | 203.68 | -17.68 | 121.72 | 0.3485 | -1022.0 | -749.8 | |
| 0.00 | 3.06 | 0.00 | 1.61 | -12.25 | 203.63 | -17.73 | 118.07 | 0.3388 | -791.0 | -515.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
