SDO HMI 2011-01-03 19:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 85.41 | 287.57 | 43.80 | 147.36 | -14.10 | 207.93 | -10.12 | 138.61 | 0.2577 | -96.7 | -49.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-01-03 19:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.95 | 0.00 | 1.00 | -15.61 | 211.43 | -6.61 | 152.57 | 0.2419 | 1046.0 | 805.5 | |
| 1.95 | 87.54 | 0.99 | 44.50 | -14.74 | 211.00 | -7.05 | 149.18 | 0.2326 | 977.1 | 548.2 | |
| 15.62 | -2.00 | 7.95 | -2.00 | -14.44 | 210.95 | -7.10 | 148.29 | 0.2287 | 1290.7 | 999999 | |
| 1.44 | -2.00 | 0.74 | -2.00 | -14.80 | 210.82 | -7.23 | 148.66 | 0.2351 | 905.7 | 999999 | |
| 0.00 | 1.36 | 0.00 | 0.69 | -14.04 | 209.83 | -8.22 | 143.44 | 0.2339 | 954.0 | 737.1 | |
| 0.00 | 1.70 | 0.00 | 0.87 | -15.21 | 209.75 | -8.29 | 146.09 | 0.2507 | 836.0 | 725.8 | |
| 13.59 | 21.91 | 6.92 | 11.16 | -13.80 | 209.56 | -8.49 | 141.92 | 0.2334 | 1114.7 | 670.4 | |
| 2.04 | 9.85 | 1.04 | 5.04 | -14.61 | 209.28 | -8.76 | 143.16 | 0.2470 | 874.0 | 597.6 | |
| 3.40 | -8.00 | 1.74 | -8.00 | -14.84 | 209.12 | -8.93 | 143.25 | 0.2519 | 875.1 | 999999 | |
| 0.00 | 1.87 | 0.00 | 0.95 | -14.15 | 209.06 | -8.99 | 141.29 | 0.2434 | 551.0 | 324.2 | |
| 0.00 | 0.76 | 0.00 | 0.39 | -14.39 | 208.95 | -9.09 | 141.61 | 0.2476 | 614.0 | 410.7 | |
| 0.00 | 1.27 | 0.00 | 0.65 | -13.76 | 208.92 | -9.13 | 139.80 | 0.2399 | 643.0 | 507.2 | |
| 0.00 | 2.29 | 0.00 | 1.17 | -13.40 | 208.69 | -9.36 | 138.08 | 0.2379 | 917.0 | 786.6 | |
| 0.00 | 2.63 | 0.00 | 1.34 | -13.37 | 208.47 | -9.57 | 137.36 | 0.2400 | 959.0 | 731.5 | |
| 2.04 | 4.84 | 1.05 | 2.48 | -14.96 | 208.19 | -9.86 | 140.82 | 0.2630 | -888.7 | -469.0 | |
| 0.00 | 1.19 | 0.00 | 0.61 | -14.86 | 207.98 | -10.07 | 140.00 | 0.2641 | -884.0 | -657.8 | |
| 0.76 | 2.72 | 0.39 | 1.39 | -12.76 | 207.76 | -10.29 | 133.53 | 0.2413 | 1207.2 | 967.2 | |
| 16.81 | 33.45 | 8.63 | 17.17 | -14.53 | 207.50 | -10.55 | 137.84 | 0.2653 | -1162.0 | -482.1 | |
| 2.29 | -18.00 | 1.18 | -18.00 | -14.20 | 207.20 | -10.84 | 136.19 | 0.2647 | -1176.6 | 999999 | |
| 0.00 | 0.76 | 0.00 | 0.39 | -14.04 | 206.84 | -11.21 | 134.84 | 0.2672 | 668.0 | 476.9 | |
| 0.00 | 1.70 | 0.00 | 0.87 | -13.83 | 206.63 | -11.41 | 133.75 | 0.2672 | 771.0 | 476.0 | |
| 0.00 | 3.14 | 0.00 | 1.62 | -14.04 | 206.28 | -11.77 | 133.47 | 0.2738 | -859.0 | -722.9 | |
| 0.00 | 5.43 | 0.00 | 2.79 | -13.25 | 205.98 | -12.07 | 130.56 | 0.2691 | -1076.0 | -846.9 | |
| 7.13 | 27.43 | 3.68 | 14.14 | -14.12 | 205.84 | -12.20 | 132.68 | 0.2802 | -1085.5 | -847.8 | |
| 0.00 | 1.19 | 0.00 | 0.61 | -12.47 | 205.65 | -12.40 | 127.49 | 0.2654 | -1004.0 | -858.1 | |
| 0.00 | 1.53 | 0.00 | 0.79 | -13.82 | 205.46 | -12.59 | 130.99 | 0.2817 | -928.0 | -677.2 | |
| 9.51 | 47.97 | 4.91 | 24.77 | -13.24 | 204.99 | -13.06 | 128.38 | 0.2818 | -1264.7 | -520.9 | |
| 0.00 | 1.53 | 0.00 | 0.79 | -13.93 | 204.89 | -13.16 | 130.09 | 0.2901 | -1079.0 | -878.9 | |
| 2.97 | -27.00 | 1.54 | -27.00 | -13.45 | 204.61 | -13.44 | 128.18 | 0.2889 | -1041.6 | 999999 | |
| 0.00 | 1.53 | 0.00 | 0.79 | -14.67 | 204.53 | -13.52 | 131.33 | 0.3025 | -881.0 | -776.4 | |
| 5.86 | 10.78 | 3.04 | 5.59 | -13.95 | 204.39 | -13.66 | 129.14 | 0.2968 | -1059.3 | -844.1 | |
| 0.00 | 1.70 | 0.00 | 0.88 | -14.04 | 204.13 | -13.92 | 128.87 | 0.3010 | -876.0 | -695.2 | |
| 0.00 | 3.65 | 0.00 | 1.90 | -14.61 | 204.00 | -14.05 | 130.11 | 0.3085 | -484.0 | -677.5 | |
| 0.00 | 0.59 | 0.00 | 0.31 | -14.36 | 203.86 | -14.19 | 129.21 | 0.3078 | -792.0 | -647.6 | |
| 0.00 | 1.95 | 0.00 | 1.01 | -13.58 | 203.66 | -14.39 | 126.75 | 0.3028 | -1025.0 | -877.7 | |
| 0.00 | 1.36 | 0.00 | 0.70 | -12.00 | 203.72 | -14.33 | 122.31 | 0.2877 | -876.0 | -710.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
