SDO HMI 2011-01-04 21:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 71.84 | 408.52 | 45.00 | 255.83 | 31.28 | 188.50 | -15.27 | 21.62 | 0.6129 | -1126.7 | -335.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-01-04 21:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.27 | 0.00 | 0.76 | 29.74 | 196.02 | -7.76 | 12.10 | 0.5611 | -668.0 | -559.0 | |
| 0.00 | 1.10 | 0.00 | 0.67 | 29.77 | 192.95 | -10.82 | 16.60 | 0.5725 | -683.0 | -500.1 | |
| 66.07 | 396.65 | 41.28 | 248.18 | 31.25 | 188.60 | -15.17 | 21.53 | 0.6120 | -1319.6 | -343.1 | |
| 1.27 | -3.00 | 0.80 | -3.00 | 31.01 | 188.00 | -15.77 | 22.46 | 0.6121 | -813.1 | 999999 | |
| 1.61 | -3.00 | 1.02 | -3.00 | 31.52 | 187.70 | -16.08 | 22.47 | 0.6200 | -626.0 | 999999 | |
| 0.00 | 0.93 | 0.00 | 0.57 | 28.42 | 187.19 | -16.58 | 25.53 | 0.5845 | -695.0 | -588.5 | |
| 2.89 | 3.65 | 1.90 | 2.40 | 33.83 | 185.55 | -18.22 | 23.31 | 0.6587 | 779.5 | 645.4 | |
| 0.00 | 2.29 | 0.00 | 1.47 | 31.74 | 185.55 | -18.22 | 24.88 | 0.6344 | -633.0 | -436.2 | |
| 0.00 | 2.63 | 0.00 | 1.78 | 33.88 | 181.41 | -22.37 | 27.68 | 0.6825 | 627.0 | 568.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
