SDO HMI 2011-01-05 05:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 6.96 | 15.95 | 10.53 | 25.71 | 34.03 | 264.91 | 65.52 | 307.60 | 0.9519 | 92.1 | -50.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-01-05 05:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.12 | 0.00 | 4.28 | 33.56 | 269.81 | 70.42 | 305.92 | 0.9706 | -205.0 | -155.6 | |
| 1.70 | 3.31 | 2.99 | 5.84 | 32.95 | 267.33 | 67.94 | 305.85 | 0.9608 | -225.5 | -261.3 | |
| 0.00 | 0.59 | 0.00 | 1.03 | 33.07 | 266.96 | 67.57 | 306.06 | 0.9595 | -384.0 | -324.0 | |
| 0.00 | 0.76 | 0.00 | 1.31 | 33.62 | 266.54 | 67.15 | 306.72 | 0.9586 | -168.0 | -166.9 | |
| 1.19 | 2.29 | 1.91 | 3.68 | 33.71 | 265.07 | 65.68 | 307.17 | 0.9527 | 203.1 | 167.8 | |
| 0.42 | 1.53 | 0.65 | 2.33 | 33.89 | 263.81 | 64.41 | 307.69 | 0.9475 | 183.4 | 93.6 | |
| 3.65 | 4.08 | 4.98 | 5.55 | 35.59 | 259.96 | 60.57 | 310.51 | 0.9332 | 388.3 | 481.4 | |
| 0.00 | 1.27 | 0.00 | 1.69 | 35.65 | 259.09 | 59.69 | 310.85 | 0.9291 | 329.0 | 271.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
